Dry Powder Mortar Mixer for Tile adhesive, Refractory Materials,
Building Materials
Specifications:
| Model | Power ( kw ) | Speed ( r/min ) | Cylinder Size (mm) | Outer Size ( mm ) | Total Volume |
| 300 | 2.2 | 24 | φ680*1250 | 2100*700*1450 | 450L |
| 500 | 5.5 | 24 | Φ800*1670 | 2800*810*1780 | 850L |
| 1000 | 7.5 | 24 | Φ1050*1880 | 3200*1100*2000 | 1800L |
| 2000 | 11 | 24 | Φ1350*2400 | 3600*1350*2600 | 3500L |
Introduction of Dry Mortar Mixer:
CV≤5%-7%,Mixing time 3-6 minutes. It uses manual operating,
electric driving and steam driven wide opening discharge. Residual
in the machine is little. It can be widely used in feedstuff
plants, cultivation farms, chemical plants, food products
factories, flourmills, etc.
The horizontal ribbon mixer is mainly used to powder and liquid
,granule, flake and miscellaneous materials mixing, like Feed,
Food, Pharmaceutics; Agriculture; powder metallurgy, chemical,
ceramics.
Working Principles of Building Materials Mixer:
Mind series multi- helical ribbon mixer through high-speed rotating
of stirring shaft, make internal and external spiral flipping
materials in a wide range, internal helix transmitting the material
from center to sides, the external spiral gathering the material
from sides to center to form convection mix. outside screw
gathering the material from sides to center, and part of the
material along the axial radial motion to form convection mix and
achieve all-round no dead angle depth mixtuer, so as to fast and
uniformly mixing the material in a relatively short period of time.
Main Features of Refractory Materials Powder Mixer:
1. With simple and reasonable structure, convenient maintenance,
safe and reliable, high mixing evenness, short mixing time, little
residuals;
2. Can be used as the compound feed unit for medium and small sized
farm;
3. Applicable to coating, try powder, chemical industry, used to
mix various dry powders metered in proportion.
4. The operation is simple in the production process.the generator
drives the reducer,and the reducer drives the agiator shaft for
stirring.
5. The machine itself can also add cooling and heating functions
according to customers requirements.The fuselage small footprint.
